The 2026 Harley-Davidson® CVO™ Street Glide® is a factory-engineered touring motorcycle that combines a high-displacement engine, a structurally reinforced chassis, and a fully integrated electronics system. This model is designed with a focus on measurable performance, mechanical reliability, and long-distance riding capability. The motorcycle uses a Milwaukee-Eight® VVT 121 powertrain, a 6-speed transmission, and a belt-driven final drive system. It also incorporates a 12.3-inch TFT display with Skyline™ OS, multiple rider safety systems, and a comprehensive braking package.
Engine Configuration and Output Characteristics
The 2026 Harley-Davidson® CVO™ Street Glide® is equipped with the Milwaukee-Eight® VVT 121 engine. This engine features a displacement of 121 cubic inches, equivalent to 1,977 cubic centimeters. It uses a pushrod-operated overhead valve configuration with four valves per cylinder and hydraulic self-adjusting lifters. The bore measures 4.075 inches, and the stroke measures 4.625 inches. The compression ratio is set at 11.4:1. Fuel delivery is managed through an electronic sequential port fuel injection system, which supports consistent fuel atomization and controlled combustion.
The engine uses a pressurized dry-sump lubrication system, which separates oil storage from the crankcase to improve thermal management and lubrication efficiency. Air intake is handled through a synthetic felt, washable air cleaner. Exhaust gases exit through a 2-1-2 dual exhaust configuration. These combined systems are engineered to maintain stable operating temperatures and consistent airflow through the engine.
Performance output is rated at 115 horsepower at 4,500 revolutions per minute. Torque output is rated at 139 foot-pounds at 3,000 revolutions per minute. The torque curve emphasizes lower engine speeds, which supports acceleration without requiring high rpm input. This configuration supports steady performance during highway cruising and under load conditions such as passenger riding or luggage transport.
Transmission and Drivetrain Architecture
The drivetrain system of the 2026 Harley-Davidson® CVO™ Street Glide® includes a 6-speed Cruise Drive® transmission. Power transfer begins with a chain-driven primary system that uses a 34/46 ratio. The final drive is belt-driven with a 32/68 ratio. This combination reduces maintenance requirements while maintaining consistent power delivery.
The clutch is a mechanically actuated 10-plate wet system with Assist and Slip functionality. This design reduces lever effort during operation and minimizes rear wheel instability during downshifting. The gear ratios are configured to provide a wide operational range. First gear has an overall ratio of 9.593, followed by 6.65 in second gear, 4.938 in third gear, 4.0 in fourth gear, 3.407 in fifth gear, and 2.875 in sixth gear. These ratios allow for controlled low-speed movement and stable highway cruising at reduced engine speed.
Structural Framework and Dimensional Engineering
The chassis of the 2026 Harley-Davidson® CVO™ Street Glide® is constructed using a mild steel tubular frame. The frame includes a two-piece stamped and welded backbone, along with cast and forged junctions that enhance rigidity. The structure incorporates twin downtubes and a bolt-on rear frame section with forged fender supports. The swingarm is constructed from a mild steel two-piece drawn and welded assembly with forged junctions. These elements contribute to overall structural integrity and load distribution.
The motorcycle measures 94.9 inches in length, with an overall width of 38.4 inches and a height of 53.1 inches. The wheelbase is 64 inches. The rake angle is 26 degrees, and the fork angle is 30 degrees. The trail is measured at 6.7 inches. These geometry figures are selected to maintain directional stability while allowing controlled steering input.
Seat height is 26.7 inches when laden and 28.2 inches when unladen. Static ground clearance is 5.5 inches. These measurements provide a low center of gravity and consistent rider positioning. The motorcycle has a lean angle capability of 32 degrees on both the left and right sides, supporting controlled cornering under standard riding conditions.
Suspension Systems and Ride Control
The front suspension system uses 47 mm inverted 1x1 front forks. This design improves front-end rigidity and maintains consistent damping performance under braking and cornering loads. Rear suspension is managed by dual adjustable emulsion shocks. The left shock includes remote preload adjustment, and the right shock includes threaded preload adjustment. This configuration allows for load-specific tuning based on passenger weight or cargo.
Front suspension travel is 4.6 inches, while rear suspension travel is 3.0 inches. These measurements are aligned with touring requirements, balancing ride comfort and stability. The suspension system is designed to absorb irregularities in road surfaces while maintaining predictable chassis behavior.
Wheel Configuration, Tires, and Braking Components
The 2026 Harley-Davidson® CVO™ Street Glide® uses gloss black nine-spoke cast aluminum wheels. The front wheel has a diameter of 19 inches and a width of 3.5 inches. The rear wheel has a diameter of 18 inches and a width of 5 inches. Tire specifications include a Dunlop® Harley-Davidson® Series D408F front tire in 130/60B19 configuration and a D407T rear tire in 180/55B18 configuration. These tire dimensions support load capacity and traction.
The braking system includes dual floating front rotors with a diameter of 12.6 inches. The front calipers are 32 mm four-piston fixed units mounted in a radial configuration. The rear braking system includes a single fixed rotor measuring 11.8 inches, paired with an axially mounted caliper. An anti-lock braking system is included as standard equipment. The braking system is designed to provide consistent stopping performance under varying load conditions.
Performance Metrics and Operational Data
The motorcycle produces 139 foot-pounds of torque at 3,000 revolutions per minute and 115 horsepower at 4,500 revolutions per minute. Lean angle capability is measured at 32 degrees on both sides. These performance figures indicate the motorcycle’s ability to maintain stable operation during acceleration and cornering.
Fuel capacity is 6 gallons, with a reserve capacity of 1 gallon indicated by a warning system. The motorcycle achieves an estimated fuel economy of 45 miles per gallon. The oil capacity with the filter is 5 quarts. Transmission capacity is 1 quart, and the primary chain case capacity is 1.1 quarts. Coolant capacity is 0.82 quarts.
The motorcycle weighs 800 pounds as shipped and 838 pounds in running order. The gross vehicle weight rating is 1,360 pounds. Front axle weight rating is 500 pounds, and rear axle weight rating is 927 pounds. Luggage capacity is measured at 2.2 cubic feet, providing storage for extended travel requirements.
Electrical System and Integrated Components
The electrical system includes a sealed, maintenance-free 12-volt battery rated at 28 amp-hours with 405 cold cranking amps. Charging is managed by a three-phase 58-amp system capable of producing up to 754 watts at 13 volts. The starting system uses a 1.6 kW electric starter with solenoid shift engagement.
Lighting systems include LED headlamps, LED tail and stop lamps, LED front signal lamps, and LED rear turn signals. These components provide consistent illumination and reduced power consumption. Digital gauges are integrated within the display system, consolidating rider information.
The motorcycle includes a 15-watt USB-C power outlet located in the media storage compartment. An embedded navigation system is included, with connectivity for traffic and weather updates through a Wi-Fi hotspot connection. These features are integrated into the electrical architecture of the motorcycle.
Infotainment System and Connectivity Features
The infotainment system is based on Skyline™ OS and is displayed on a 12.3-inch full-color TFT screen. The system integrates vehicle data, navigation, and media functions into a single interface. Audio output is delivered through four speakers, with two 6.5-inch speakers mounted in the fairing and two 5 by 7-inch speakers mounted in the saddlebags. Each channel delivers 125 watts of power.
The system supports AM and FM radio. USB media playback is supported through a USB-C connection located in the inner fairing storage area. Hands-free mobile phone connectivity is enabled through Bluetooth®. The system also supports Apple CarPlay® in both wireless and wired configurations. Rider and passenger intercom functionality is included, with compatibility for wireless Bluetooth® headsets.
Rider Safety and Control Systems
The 2026 Harley-Davidson® CVO™ Street Glide® includes a comprehensive set of rider safety systems. Standard features include Anti-lock Braking System, Electronic Linked Braking, Traction Control System, Drag-torque Slip Control System, Vehicle Hold Control, and Tire Pressure Monitoring System. These systems monitor and adjust braking and traction parameters to maintain stability.
The motorcycle also includes cornering-enhanced systems. These include Cornering Enhanced Anti-lock Braking System, Cornering Enhanced Electronic Linked Braking, Cornering Enhanced Traction Control System, and Cornering Drag-Torque Slip Control System. These systems adjust performance based on lean angle input, supporting control during cornering.
